Titanium stud technical specs, Ti-6Al-4V stud dimensions, titanium fastener tolerance standards, metric titanium studs
| Model no. | LS-SC04 |
| Material | Ti-6Al-4V Grade 5 Titanium Alloy (Ti 6% Aluminum, 4% Vanadium) |
| Size | M6, M8, M10, M12, M14, M16 (metric); 1/4″, 3/8″, 1/2″ (imperial) |
| Seat Type | 60° Conical/Tapered Seat (also available in ball seat on request) |
| Length | 20mm – 200mm (unequal-length design: thread length ratio 1:1.5/1:2) |
| Tensile Strength | Min. 860 MPa |
| Yield Strength | Min. 820 MPa |
| Hardness | 30-36 HRC |
| Finish | Mill finish (raw titanium) / Anodized (black, blue, gold—customizable) |
We’ve compiled answers to the most frequently asked questions about our titanium alloy double end studs to help you make informed decisions:
Q: Can titanium alloy double end studs replace stainless steel studs in all applications?
A: Titanium studs are a direct replacement for stainless steel (304/316) in most industrial, automotive, and marine applications—except for high-temperature environments above 400°C (titanium’s strength degrades above this temperature; Inconel or nickel-alloy studs are better for these cases).
Q: Do Ti-6Al-4V studs require surface treatment (e.g., anodizing)?
A: Raw titanium studs have a natural oxide layer that provides corrosion resistance, so anodizing is optional. Anodizing adds a colored finish (aesthetic) and slightly enhances scratch resistance but does not improve corrosion performance.
Q: What torque value should I use for titanium studs?
A: As a general rule, torque titanium studs to 70-80% of the torque specified for steel studs of the same size. Always refer to your equipment’s service manual for application-specific torque values—over-torquing is the leading cause of titanium stud failure.
Q: Can I customize the length/thread size of titanium studs?
A: Yes—we offer custom machining for titanium double end studs (M6-M24 metric, 1/4″-1″ imperial) in lengths from 20mm to 300mm. Contact our engineering team for custom quotes and lead times.
Key Keywords Embedded: titanium stud FAQs, Ti-6Al-4V stud common questions, titanium stud warranty, custom titanium studs
